图象传感器\Image Sensor
|
1/3〞SONY CCD
|
|
有效像素\Effective Pixels
|
PAL:512(H)×582(V) NTSC: 512(H)×492(V)
|
|
信号系统\Signal System
|
PAL/NTSC
|
|
水平清晰度\Horizontal Resolution
|
420TV lines
|
|
快门速度\Shutter Speed
|
1/50(1/60)—1/100,000sec
|
|
信噪比\S/N Ratio
|
More than 48db(AGC OFF)
|
|
最低照度\Minimum Illumination
|
0Lux At Night(LED ON)
|
|
视频输出\Video Output
|
1.0Vp-p,75Ω
|
|
工作温度\Operation Temperature
|
-10℃~+50℃ RH95％Max
|
|
功率消耗\Ppwer Consumperature
|
DC 12V 120Ma(When the infrared Lamps turn on maxim electricity is 300mA)
|
|
内置镜头\Built-Lens
|
3.6mm/6mm
|
|
红外线波长\Infraed Wave length
|
850nm
|
|
红外线自动开关\Infraed Lamps Lrradiation Kistance
|
Night/Day Opening/Turn off
|
|
尺寸\Dimensions
|
Φ60(W)×70(H)×140(L)mm
|
|
净重/毛重\NW/GW
|
490g/610g
|
|
红外灯数量\LED number
|
Φ5 24PCS
|
|
红外灯距离\Infraed Lamps
|
25m
|
